ITEM

BRICK

PRODUCTION/CAPACITY

BRICK/CYCLE
BRICK/HOUR

28 BRICK PER CYCLE
5040 BRICK PER HOUR

SIZE BRICK

PER PIECE (MM)

100 X 67 X 220

BRICK TYPE AND PROCESS

CEMENT CONCRETE WITH UPSIDE-CENTER LINE

28 BRICK/CYCLE

MACHINE COMPONENTS

STANDARD BRICK/BLOCK SIZE MOULD

1 UNIT

PLC MAIN CONTROL BOX (PROGRAMMABLE LOGICAL CONTROLLER)

1 UNIT

HYDRAULIC TANK & VALVES UNITS

1 UNIT

AUTOMATIC PALLET LOADER

1 UNIT

CONCRETE PAN MIXER

1 UNIT

SAND HOPPERS

2 UNIT

BELT DRIVEN CONVEYORS

2 UNIT

BELT DRIVEN CONVEYORS SET FOR SAND HOPPERS

2 UNIT

MANUAL ROLLER CONVEYOR FOR END PRODUCTS

1 UNIT

AUTOMATIC CHAIN CONVEYOR + GANTRY HOIST SYSTEM FOR END PRODUCTS (OPTIONAL)

1 UNIT

HAND LOADER FOR END PRODUCTS (OPTIONAL)

1 UNIT

SPECIFICATION

MOTOR

3 HP 230V S/P 50HZ

3 HP 415V 3 PHASE 50HZ

OPERATING SYSTEM

MAKING BRICK

PUSH VIBRATION BUTTON
PUSH UP BUTTON
PUSH DOWN BUTTON

RELEASE BRICK

AUTOMATIC
